Wheeled Tractor

Compact Tractor

  • The engine is Direct drive
  • Two/four wheel drive
  • Perfect in performance of Hydraulic suspension system
Compact Tractor

The compact tractor

A compact tractor is a flexible and efficient agricultural machine specifically designed for narrow fields and diverse tasks. It can easily handle plowing, seeding, and transportation, and it boasts high maneuverability, making it suitable for various terrains and crops. This type of tractor helps farmers manage their farms more efficiently in limited spaces, improving operational efficiency and reducing labor intensity. Whether for family farms or small plantations, a compact tractor is an ideal choice for enhancing productivity and meets the modern agricultural demand for efficient and reliable equipment.

The Advantage of Compact Tractor

  • The engine is Direct drive
  • Two/four wheel drive
  • Shuttle shift : 8+8 gear transmission
  • double speed power output:540/1000
  • Hydraulic steering system

  • 40-70A type tractor is designed base on 40-65HP Series tractor, it combine new technology and new structure together. It has the advantages of suitable power, large traction, compact structure, high transmission efficiency, easy to operate, easy to maintain, convenient to match, economical to use and good comprehensive utilization performance.

  • Special For Paddy Field, 70-100hp type tractor is combined new technology and new structure together. It has the advantages of suitable power, large traction, compact structure, high transmission efficiency, easy to operate, easy to maintain, convenient to match,economical to use and good comprehensive utilization performance.

  • • The engine is Direct drive
    • Two/four wheel drive
    • 4*(2+1)*2 transmission
    • Perfect in performance of Hydraulic suspension system
    • There are both Mechanical or hydraulic steering system

  •

Compact Tractor Common Specifications and Parameters

Model 404C 554 804 904
Drive Type  4WD 4WD 4WD 4WD
Overall Dimensions  L×W×H(mm)

3430x1280x1950

 4010×1752×2518

4150×1880×2735

4580×2180×2920

Wheel Bass(mm)

1825

/

2080

2315

Ground Clearance (mm)

330

325

475

390
Rated Traction Force(N)

6200

14200

19400

20800

Construction Mass(kg)

1310

2172

2810

4700

Min.Turning Radius(m)

4.0

3.7

4.1

 4
Engine Model

490BT

YT4A2-23

4G33TC

LR4M5-T79-U2
Engine Type

4-Cylinder Vertical,water cooled,4 stroke cycle

4-Cylinder、water cooled、4 stroke cycle

4-cylinder
Vertical,water cooled,
4 stroke cycle

4-cylinder
Vertical,water cooled,
4 stroke cycle

Rated Power(kw/hp)

29.4/40

29.8/40.5

59/80

66.2/90

Rated Speed (rpm)

2300

2300

2300

2300

Clutch

Dual stage

Single-function clutch

Dual stage

Dual stage

Gear Box

(4+1)*2

4*(1+1)*2

4*(3+1)*2 Sleeve gear shift

4*(2+1)*2 Sleeve gear shift

Steering Gear

Hydraulic Steering

Hydraulic steering

Hydraulic steering

Hydraulic steering

Brake

Disc type

Oil immerszd multiplate Disc

Disc type

Oil immersed multiplate disc
