Trailed Conditioner Disc Mower
- Working width(m): 2.9
- Transport width(m): 3
- Transport height(m): 2
- Blade dimensions(mm): 110x48x4
The Trailed Conditioner Disc Mower
DFTCDM-3.0 Trailed Conditioner Disc Mower can flatten the coarse straw of the grass immediately with the roller, and then throw it to the grass collecting board at high speed to form a fluffy grass strip, which can effectively improve the natural drying speed of the grass and reduce the nutrient loss of flowers and leaves.
The Advantage of Trailed Conditioner Disc Mower
- The middle traction can be used for reciprocating harvesting
- The double profiling device of hydraulic pressure and spring is adopted to make the harvest more stable
- High efficiency rubber roller to improve the breaking rate of straw.
- Other standard equipment: QCS (quick change system), spare blades, QCS tool, shear safety pins, foldable protective curtains against flying debris (CE Norm)
- Hydraulic connection: 1 x one-way hydraulic connection (1EW)；1 x two-way hydraulic connection (1DW)
-
High strength gear box on the cutter bar.
-
The cutting height can be continuously adjusted by the handle.
-
The 90°rotary drive provides good turning maneuverability.
-
The continuously adjustable rubber roller ensures the smooth operation of the machine.
Trailed Conditioner Disc Mower Common Specifications and Parameters
| Model | DFTCDM-3.0 |
|---|---|
| Working width (m) | 2.9 |
| Weight (kg) | 1880 |
| Transport width (m) | 3 |
| Transport height (m) | 2 |
| Number of discs | 7 |
| Number of blades | 14 |
| Blade dimensions(mm) | 110*48*4 |
| Disc rotation speed (rpm) | 3000 |
| PTO rotation speed (rpm) | 1000 |
| Capacity (ha/h) | 3.5 |
| Required tractor power (kW/HP) | 60/80 |
| Max. working speed (km/h) | 18 |
| Cutting height (mm) | 40-70 |
| Disc rotation | paired |
| Conditioner | rubber roller |
| Safety clutch (Nm) | 1500 |
| Assembly time (h) | 2 |
